STH-40 Series Series Thermal Overload Realy

Sth-40 Series Thermal Overload Realy inokodzera Dunhu reAc 50/60 Hz, Rated Mashandiro Ekupedzisira Kusvikira pa660V. Uye inogona kuziva basa rekunyanyisa uye chikamu-kukundikana kuchengetedzwa kwe AC mota. Ichi chigadzirwa chinogunun'una kuGB1404048.4, Iec60947-4-1 chiyero.

Model:STH-40

Send Inquiry

Product Description

Main technical paramende:

Modhi	Zvazvino	Yakakodzera vatauri
Sth-22/3	0.4-63a	Gmc-9 ~ 22
Sth-22/3	0.63-1A	Gmc-9 ~ 22
Sth-22/3	1-1.6a	Gmc-9 ~ 22
Sth-22/3	1.6-.5a	Gmc-9 ~ 22
Sth-22/3	2.5-4a	Gmc-9 ~ 22
Sth-22/3	4-6a	Gmc-9 ~ 22
Sth-22/3	5-8A	Gmc-9 ~ 22
Sth-22/3	6-9a	Gmc-9 ~ 22
Sth-22/3	7-10a	GMC-12 ~ 22
Sth-22/3	9-13a	GMC-12 ~ 22
Sth-22/3	12-18a	Gmc-18 ~ 22
Sth-22/3	16-22A	Gmc-22
STH-40/3	18-26a	GMC-32 ~ 40
STH-40/3	24-36A	GMC-32 ~ 40
STH-40/3	28-40	GMC-40
Sth-85/3	34-50a	Gmc-50 ~ 85
Sth-85/3	45-65a	Gmc-50 ~ 85
Sth-85/3	54-75a	Gmc-65 ~ 85
Sth-85/3	63-85A	Gmc-75 ~ 85

STH-40 Series Thermal Overload Relay

Mabasa makuru

Dziviriro yeMotor: Iyo huru basa reiyo iyo inozenza yakawandisa yekudzokorora ndeyekudzivirira mota kubva mukukuvara nekuda kwekunyanyisa. Kana mota yanyoreswa, iyo inowedzera kudzokorora yekudzokorora inobvisa simba nguva nenguva yekudzivirira mota kubva mukupisa nekuda kwekundedera.

Dziviriro yemidziyo yemagetsi: Pamusoro pekuchengetedza mota, iyo yekunyora yekudzokorora yekudzokorora inogona zvakare kudzivirira iyo midziyo yemagetsi. Mota painenge yakurisa, yazvino inozowedzera, iyo inogona kutungamira mukunyanyisa nekunyungudika kwemitsetse yemagetsi. Nekuona shanduko yazvino, iyo yekunyora yakadzama inotaura kuti ingave iri rondedzero yemagetsi yakadzvanywa uye ichicheka kubva pane simba rekuwanikwa kana zvichidikanwa.

Kuvandudza kuchengetedzeka kwesimba system: thermal yakadzorerwa runyararo kunogona kudzivirira kukuvadzwa kwemota uye mutsara wemagetsi, nekudaro kudzora huwandu hwekutadza kwehurongwa hwemagetsi uye nekuvandudza kuchengetedzeka kwehurongwa hwemagetsi.

Nheyo yekuvhiya

Nheyo yekushandisa yekudyara yeiyo yekunyora yakanangana neyakawedzera kubva pane iyo yazvino inowedzera maitiro uye tembiricha yekunzwa zvivakwa zvebhenji. Kana kuwanda kunoitika mumota, iko kwazvino kunowedzera, zvichikonzera kupisa kwakawanda kuti kugadzirwa muchimiro chekudziya chehunhu hwekuputika kwekunyora. Kupisa uku kunoendeswa kune iyo Bimeta, iyo inokotama kana ichipiswa nekuti yakagadzirwa neyakajairwa maviri nemisiyano yakakura mumabhegi ekuwedzera kwemutsara. Kana iyo Bimetal inokotama kune imwe nhanho, ichakonzera iyo electromagnic coil kuti ishandiswe, iyo ichitungamira ichatyaira vafambi kuti vaite uye vachicheka mvura yemagetsi yemota.

Chiyero chekushandisa

Thermal yakanyanya kudzokorora inowanzo shandiswa mumatunhu ane ac 50hz, yakarongedzwa insolation ye660 Inogona zvakare kushandiswa kuumba mutambi neanoshandurwa AC Contactor kuti ipe zvakazara kuchengetedza mota.

Zvigadzirwa zvechigadzirwa

Kuumbwa kwakareruka: Iyi inowedzera kurongedza yekudzokorora inowanzo tora iyo yakapusa chimiro dhizaini, zvichiita kuti zvive nyore kuisa uye kushandisa.

Yakazara-Inoratidzwa: Pamusoro peiyo yekutanga yekudzivirirwa yekudzivirira basa, zvakare ine mabasa echivimbo chekudzivirirwa kwekudzivirira uye tembiricha yekushambadzira.

Mutengo wakaderera: uchienzaniswa nemamwe madhiri ekudzivirira mota, mutengo wekutengesa wakawanda wekudzokera shure kwekudzokorora kwakadzika, izvo zvinoderedza mutengo wekutenga wevashandisi.

Yakagadzikana kushanda kwekushanda: nekuti inotora bhaiti seyekuita chinhu chakanangana, kuita kwayo kwekushanda kwakasimba uye kuvimbika.
