WiFi ST65LE-63wf2 Series Multi Functional IoT Intelligent RCBO Intelligent Circuit Breaker

ZVINOTAURWA:

	Standard		IEC/EN  60898-1
Magetsi zvinhu	Rated current In	A	1,2,4,6,10,16,20,25,32,40,50,63
	Poles	P	1,2,3,4
	Rated voltage Ue	V	AC   230/400;  240/415
	Insulation voltage Ui	V	500
	Rated frequency	Hz	50/60
	Rated breaking capacity	A	4500  ;6000
	Rated impulse inomira voltage (1.2/50) Uimp	V	4000
	Dielectric test voltage pa ind.Freq.for 1 min	Kv	2
	Dhigirii rekusvibisa		2
	Thermo-magnetic kusunungurwa maitiro		B,C,D
Mechanical features	Upenyu hwemagetsi	t	4000
	Mechanical hupenyu	t	10000
	Dhigirii rekudzivirira		IP20
	Reference tembiricha yekuseta	ºC	30
	ye thermal element
	Ambient tembiricha	ºC	-5 ~+40(Chishandiso chakakosha ndapota tarisa kune
	(neavhareji yezuva nezuva ≤35ºC)		kururamisa tembiricha muripo)
	Kuchengetedza tembiricha	ºC	-25~+70
Installation	Terminal yekubatanidza mhando		Cable/Pini-mhando yebhazi
	Terminal size kumusoro/pasi kwetambo	mm2	25
		AWG	18-3
	Therminal size kumusoro/pasi kwebusbar	mm2	25
		AWG	18-3
	Kuomesa torque	N*m	2
		In-lbs	18
	Mounting		paDIN njanji EN 60715(35mm) nenzira yekukurumidza clip mudziyo
	Connection		Kubva kumusoro uye pasi

Iyo WiFi Smart Circuit Breaker chishandiso chekudzivirira chedunhu chine yakasanganiswa yeWi-Fi yekutaurirana tekinoroji, iyo inobvumira vashandisi kudzora kure mamiriro ekuchinja kwedunhu chero nguva, chero kupi kuburikidza ne smartphone kana imwe smart kifaa. Iyi yedunhu breaker haingopi echinyakare kuwandisa uye kupfupi-sekete dziviriro, asi zvakare inounza zvisina kumboitika uye kuchinjika kune vashandisi kuburikidza neWi-Fi yekubatanidza.

Basa Rinoratidza

ST65LE-63  series WiFi Smart Circuit Breaker is a multi-function intelligent switch inobatanidza mabasa emagetsi metering, overload, short circuit, over and under voltage, leakage, over-temperature protection, remote kuvhura nekuvhara, nguva, network network zvichingodaro. Inogona kushandiswa zvakanyanya munzvimbo dzakangwara dzekutonga masimba senge commerce, kurima, zvikoro, zvipatara, mahotera, nzvimbo dzevaraidzo, zviteshi, zvetsika zvekuchengetedza zvisaririra, maguta emumugwagwa mwenje manejimendi nekudzora, uye inogona zvakare kushandiswa zvakanyanya mukushandiswa kwesimba rekushandisa mumaindasitiri nemabhizinesi emigodhi, zvivakwa zvehofisi nedzimwe nzvimbo.

Application

Iyi WIFI yakangwara inodzokorodza yedunhu breaker inogona kushandiswa zvakanyanya mudzimba, mafekitori, sduent dormitroy, mapurazi, mabasa emuicipal uye anogona nehungwaru kudzora pombi yemvura, hita yemvura, yepasi pevhu yekudziya equiement, nezvimwe.

Function

Iyi  reclosing circuit breaker inokodzera 50Hz/60Hz, 230/400V 0~125A dunhu rine basa rakadai sekudzivirira kuwandisa, kuchengetedzwa kwedunhu pfupi uye kudzivirira kwega. Zvichakadaro, iyi yakangwara inodzoreredza yedunhu inotyora ine basa se switched oof / papasirese kudzora kure nefoni smart.
